Sujoy Enterprises is notable **dowel pin suppliers, dealers, traders in India**. Producing an all-purpose array of sealing and insulating materials, we are quality-oriented. We are making use of the latest technology to make their specialized products.
As small as they are, dowel pins are giants as far as making mechanical assemblies fully aligned and structurally stable are concerned. we have a high-tech policy that guarantees each of our products to be of high standards.
We are your reliable partner, and we will do our best to offer you the best dowel pins which will fulfill all your business requirements by being as accurate and durable as possible. SS dowel pin, mild steel spring dowel pin, stainless steel dowel pins like this.
Types of Dowel Pin:
Being as recommended **dowel pin suppliers in India**, we provided different types according to necessary which are given below.
-
Straight/Standard Dowel Pins: This is the most typical and has the same diameter over its entire length. Their various applications are mainly in general alignment and fastening in a broad spectrum of uses.
-
Grooved Dowel Pins: These pins have longitudinal grooves on their surface that gives them a better grip. The grooves enable the escape of air and overflowing adhesive making it best suited to blind holes and where a very tight fit is necessary.
-
Tapered Dowel Pins: These pins are slightly tapered at one end to the other, and when driven into a tapered hole, tend to lock into place. This design provides a highly tight and vibration-resistant fit over high load connections.
-
Stainless Steel Dowel Pins: The stainless-steel dowel pins find application in high precision and life cycle applications, especially in environmentally hostile or corrosive situations where alternative materials could easily rust or degrade.
-
Spring Dowel Pins: Its springing nature enables them to compress during installation which gives them constant outward tension resulting in a non-vibrating fitting that does not need tight tolerances in the holes.
Technical Specification of Dowel Pin:
We have added below a technical sheet of **dowel pin in India** that provides more technical information such as:
| Specification |
Details |
| Common Materials |
Hardened Steel, Stainless Steel, Brass |
| Hardness (Steel) |
Case Hardness: >60 HRC; Core Hardness: 47-58 HRC |
| Diameter Tolerance |
Metric: m6 (press fit), h7 (slip fit); Imperial: +0.0002" |
| Surface Finish |
Max 0.4 µm (8 microinches) |
| Standards |
ISO 8734, DIN 6325, ASME B18.8.2 |
| End Shape |
Chamfered or Radiused ends for easy installation. |
Benefits / Features of Dowel Pin:
As **dowel pin dealers in India**, we provided according to stability different benefits which are given below.
-
Exact Alignment: These are produced with very high tolerances to ensure the proper and consistent placement of components that mate. This **dowel pin traders in India** plays an important role in the proper running of the machines.
-
Increased Structural Strength: Cylindrical dowel pin, spring dowel pin takes tensile loading, by holding parts together with a tight fit. This eliminates stress on other fasteners including screws and bolts, and provides strength and stability in the assembly.
-
Vibration Resistance: Tightly-fitting, especially grooved, taper pins, such as dowel pins, resist vibration. This will not permit the components to be displaced or even to become free with time, thereby ensuring the stability of the assembly.
-
Easy Assemble and disassemble: It provide a non-permanent fastening system that is non-threaded and very easy to assemble and disassemble. This makes it easier to manufacture and easy to maintain or repair or replace parts.
-
Cost-Effectiveness: **Dowel pin suppliers in India** are a low-cost solution that enhances the quality and the durability of the final product considerably. The reusability, and product life cycle they introduce make them a very cost-effective option.
Applications of Dowel Pin:
Serve as recommended **dowel pin traders in India**, these are applicable in different industries which are given below.
-
Automotive Industry: Widely used in assembling engines to ensure that important components of the engine such as the cylinder head and engine block are aligned. They provide flawless fit to provide optimum performance and efficiency.
-
Industrial Machinery and Manufacturing: It will be used in assembling machines to align gears, shafting and other moving components. These **dowel pin dealers in India** provide accuracy, easy working, and less wear and tear.
-
Aerospace Industry: In this in aircraft manufacturing are used in the accurate assembly of structural components as well as engine parts. These Dowel Pins & Sellok Pins, standard dowel pin sizes in mm should be safe and stable under high stress and vibration.
-
Tool and Die Making: Basically, required to ensure the accurate contact between a punch and a die when stamping. **Dowel pin suppliers in India** guarantee proper and uniform production of parts.
-
Furniture and Woodworking: Wood dowels are common to stabilize and fix the joints in furniture. They have a good, solid, joint with no visible discovers.
Sujoy Enterprises is premier dowel pin suppliers, dealers, traders in India** are tiny but strong parts that form the basis of modern precision engineering and production. Whether it is to align high-speed machinery or to ensure that a component is vital to the automobiles, we cannot be replaced due to the accuracy of their alignment capabilities, the increased strength that solid dowel pins, hard dowel pin 5MM offer, and withstand vibrations. Unbelievably easy, affordable, and convenient to use, we are a necessary part of any industrial operation to guarantee the workability and stability of any mechanical assembly and ensure its durability. Contact us for more details.
